Name: D275A-2 Komatsu Inner Parts 7079845620 Blade Lift Hydraulic Cylinder Seal Kit
Brand: Guangzhou Suncar Seals Co., Ltd.
SKU: 7079845620 Komatsu D275A-2
Availability: InStock

Brand Name:	SUNCAR
Model Number:	7079845620 Komatsu D275A-2
MOQ:	Trial order acceptable
Price:	Negotiation
Packaging Details:	PP bag inside, carton box outside
Payment Terms:	Western Union, L/C, T/T, , D/A, D/P, Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA(MAINLAND)

Part Number:

7079845620

AppliC.A.Tion:

Komatsu Bulldozers Blade Lift

Rod:

80MM

Bore:

130MM

Cylinder Number:

17M-63-01011

Serial Number:

10001

Supply Ability:

700 set per week

Highlight:

KOMATSU Seal Kit

Blade Lift Hydraulic Cylinder Seal Kit

Cylinder Service Kit

Product Description

D275A-2 Komatsu Inner Parts 7079845620 Blade Lift Hydraulic Cylinder Seal Kit

Product Name	Cylinder Seal Kit
Model Number	Komatsu D275A-2
Place of Origin	China(Mainland)
Brand name	SUNCAR
Packing	PP bag inside, carton box outside
Shipping Mode	By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.)
Part Number	7079845620
Payment Terms	Western Union, L/C, T/T, Money Gram, D/A, D/P
Size	Standard size
Applicable Industries	Construction works, machinery repair shops, retail, other
CertifiC.A.Tion	ISO9001
Condition	100% new
C.A.Tegory	Seal kits
Warranty	Unavailable
OEM and ODM	Welcome
Feature	Oil & high pressure & high temperature resistant
Preservation Notice	Closed, dry and avoid the sun
AppliC.A.Tion	Komatsu bulldozers blade lift
Cylinder Number	17M-63-01011
Rod	80MM
Bore	130MM
Serial Number	10001

Related Parts:

Pos.	Part No	Qty	Parts name
G-1.	707-02-X7170	[1]	CYLINDER GROUP,L.H. (FINAL COATING)
G-1.	17M-63-X1011	[1]	CYLINDER GROUP,L.H.
G-2.	707-02-X7180	[1]	CYLINDER GROUP,R.H. (FINAL COATING)
G-2.	17M-63-X1021	[1]	CYLINDER GROUP,R.H.
	17M-63-01011	[1]	CYLINDER ASSEMBLY
1	17M-63-12141	[1]	CYLINDER
2	175-63-22150	[2]	BUSHING
3	707-29-13760	[1]	HEAD,CYLINDER
4	07177-08040	[1]	BUSHING
5	707-51-80211	[1]	PACKING,ROD (KIT) Komatsu
6	195-63-92190	[1]	SEAL,DUST (KIT)
7	07179-13094	[1]	RING,SNAP
8	07000-12125	[1]	O-RING (KIT)
9	07146-02126	[1]	RING,BACK-UP (KIT)
10	07000-02130	[1]	O-RING (KIT)
11	17M-63-12120	[1]	ROD,PISTON
12	707-66-80040	[1]	CAP
13	175-63-22241	[10]	SHIM, 1.0MM
14	01011-52025	[4]	BOLT
15	01643-32060	[4]	WASHER
	17M-63-12131	[1]	PISTON ASSEMBLY
19	07000-12060	[1]	O-RING (KIT)
20	707-35-52900	[2]	RING,BACK-UP (KIT)
21	707-44-13180	[1]	RING,PISTON (KIT)
22	707-39-13110	[2]	RING,WEAR (KIT)
22A.	707-40-13051	[1]	RETAINER
23	707-40-13170	[2]	SPACER
24	707-83-10073	[4]	VALVE
25	01252-31235	[6]	BOLT
26	175-63-22160	[1]	HOOK
27	01010-51665	[1]	BOLT
28	01643-31645	[1]	WASHER
	17M-63-14100	[1]	VALVE ASSEMBLY,QUICK DROP
32	195-63-14180	[1]	SPRING
33	01642-21216	[1]	WASHER
34	195-63-14162	[1]	COLLAR
35	07000-12055	[1]	O-RING (KIT)
36	01011-51615	[2]	BOLT
38	17M-63-12270	[1]	TUBE,L.H.
38	17M-63-12170	[1]	TUBE,R.H.
39	07000-13035	[1]	O-RING (KIT)
40	01010-51055	[2]	BOLT
41	01010-51060	[2]	BOLT
42	01643-31032	[4]	WASHER
43	195-63-14130	[1]	ELBOW Komatsu
44	07000-13045	[1]	O-RING (KIT)
45	01010-51270	[2]	BOLT
46	01010-51280	[2]	BOLT
47	01643-31232	[4]	WASHER
48	07000-13048	[1]	O-RING (KIT)
49	01010-51065	[2]	BOLT
50	01010-51075	[2]	BOLT Komatsu
52	17M-61-22660	[1]	TUBE,L.H.
52	17M-61-22670	[1]	TUBE,R.H.
54	07000-13038	[2]	O-RING (KIT)
55	01010-51260	[2]	BOLT
58	07282-03411	[1]	CLAMP
59	01010-51020	[2]	BOLT
61	707-88-14460	[1]	PLATE
62	01010-51025	[1]	BOLT
64	07283-23442	[1]	CLIP
65	01599-01011	[2]	NUT
	707-98-45620	[2]	SERVICE KIT
