31Y1-18480 31Y118480 Excavator Oil Seal Kit Arm Hydraulic Cylinder Fits Hyundai R360LC-7 R370LC-7
| Place of Origin | CHINA(MAINLAND) |
|---|---|
| Brand Name | SUNCAR |
| Model Number | 31Y1-18480 HYUNDAI R360LC-7, R360LC-7A, R370LC-7 |
| CertifiC.A.Tion | ISO9001 |
| Minimum Order Quantity | Trial order acceptable |
| Price | Negotiation |
| Packaging Details | PP bag inside, carton box outside |
| Delivery Time | 3-5 days after payment received(public holiday excluded) |
| Payment Terms | Western Union, L/C, T/T, , D/A, D/P |
| Supply Ability | 1000 set per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Arm Cylinder Oil Seal Kit | Warranty | Unavailable |
|---|---|---|---|
| Part No. | 31Y1-18480, 31Y118480 | Material | PU, Rubber, PTFE, NBR, HNBR, ACM, VMQ |
| Sample | Available | Condition | New, Genuine New |
| High Light | HYUNDAI Seal Kit,31Y1-18480 Excavator Oil Seal Kit,Arm Hydraulic Cylinder Service Kits |
||
Product Description
31Y1-18480 31Y118480 Excavator Oil Seal Kit Arm Hydraulic Cylinder Fits Hyundai R360LC-7 R370LC-7
| Product Name | Arm Cylinder Oil Seal Kit |
| Part Number | 31Y1-18480, 31Y118480 |
| Model | 7-SERIES CRAWLER EXCAVATOR R360LC-7, R360LC-7A, R370LC-7 Hyundai |
| Material | PU, Rubber, PTFE, NBR, HNBR, ACM, VMQ |
| Place of Origin | China(Mainland) |
| Brand name | SUNCAR |
| Packing | PP bag inside, carton box outside |
| Shipping Mode | By air, by sea, by express(FedEx, UPS, DHL, TNT, etc.) |
| Payment Terms | Western Union, Paypal, T/T, Transfer |
| CertifiC.A.Tion | ISO9001 |
| Warranty | Unavailable |
| Customized | OEM & ODM are welcomed |
| C.A.Tegory Group | Hydraulic cylinder seal kit, excavator service kits |
| Condition | New, genuine new |
| Sample | Available |
| Applicable Industries |
Building material shops, machinery repair shops, retail, construction work... |
| Feature | High sealing performance/ wear resistance |
| AppliC.A.Tion | Arm |
Related Parts:
| Pos. | Part No | QTY | Product Name |
| *. | 31NA-50130 | [1] | CYLINDER ASSEMBLY |
| *. | 31NA-50131 | [1] | ARM CYLINDER |
| *. | 31NA-50132 | [1] | ARM CYLINDER ASSY |
| *-1. | 31Y1-18450 | [1] | ARM CYLINDER SUB |
| 1 | 31Y1-18730 | [1] | TUBE ASSY |
| 2 | 31Y1-23910 | [1] | ROD ASSY |
| 3 | 31Y1-08630Y | [1] | GLAND |
| 4 | S732-120050 | [1] | BUSHING |
| 5 | Y191-127000 | [1] | RING-SNAP |
| K6. | Y220-120111 | [1] | SEAL-ROD |
| K7. | Y180-120020 | [1] | RING-BACK UP |
| K8. | Y240-120013 | [1] | RING-BUFFER |
| K9. | Y110-120011 | [1] | WIPER-DUST |
| 10 | Y190-136000 | [1] | RING-SNAP |
| K11. | Y320-120000 | [1] | RING-WEAR |
| K12. | S632-160004 | [1] | O-RING |
| K13. | S642-160003 | [1] | RING-BACK UP |
| 14 | 31YC-23070 | [1] | RING-CUSHION |
| 15 | 31Y1-08642 | [1] | PISTON |
| K16. | S632-105004 | [1] | O-RING |
| K17. | S642-105003 | [2] | RING-BACK UP |
| K18. | Y420-170000 | [1] | SEAL-PISTON |
| K19. | Y310-170203 | [2] | RING-WEAR |
| K20. | Y440-170102 | [2] | RING-DUST |
| 25 | 31YC-66100 | [1] | WASHER-LOCK |
| 26 | 31YC-61263 | [1] | NUT-LOCK |
| 27 | S109-271004 | [8] | BOLT-SOCKET |
| 35 | 31YC-11201 | [2] | BUSHING-PIN |
| 36 | Y000-110100 | [4] | SEAL-DUST |
| 28 | 31Y1-08650 | [1] | BAND ASSY |
| 28 | 31Y1-22650 | [1] | BAND ASSY |
| 28-1. | 31Y1-08660 | [1] | BAND SUB ASSY |
| 28-1. | 31Y1-22660 | [1] | BAND SUB ASSY |
| 28-2. | 31YC-31260 | [1] | BAND |
| 28-3. | 31YC-37040 | [1] | CLAMP-PIPE |
| 28-3. | 31YC-37050 | [1] | CLAMP-PIPE |
| 28-4. | S015-120452 | [4] | BOLT-HEX |
| 28-4. | S015-120452 | [2] | BOLT-HEX |
| 28-5. | S411-120002 | [4] | WASHER-SPRING |
| 28-6. | S015-120502 | [2] | BOLT-HEX |
| 29 | 31Y1-18800 | [1] | PIPE ASSY-R |
| 29 | 31Y1-22670 | [1] | PIPE ASSY-R |
| 29 | 31Y1-22671 | [1] | PIPE ASSY-R |
| 30 | 31Y1-18810 | [1] | PIPE ASSY-B |
| K31. | Y171-024004 | [1] | O-RING |
| K32. | Y171-027004 | [1] | O-RING |
| 33 | S107-120554 | [4] | BOLT-SOCKET |
| 33 | S107-120604 | [4] | BOLT-SOCKET |
| 34 | S107-120654 | [4] | BOLT-SOCKET |
| 39 | 31Y1-25090 | [1] | BAND ASSY-B |
| 39-1. | 31Y1-25100 | [1] | BAND SUB ASSEMBLY |
| 39-2. | 31Y1-25110 | [1] | BAND SUB ASSEMBLY |
| 39-3. | S015-120452 | [4] | BOLT-HEX |
| 39-4. | S411-120002 | [4] | WASHER-SPRING |
| 39-5. | S071-024330 | [2] | U-BOLT |
| 39-6. | S201-101002 | [4] | NUT-HEXAGON HEAD |
| 39-7. | S411-100002 | [4] | WASHER-SPRING |
| K. | 31Y1-18480 | [1] | SEAL KIT |
Order Process:
1. Getting your inquiry (Including: machine model, part name, order quantity, data of items, delivery term)
2. Quoting our competitive price for you
3. Place an order after approving the quotation or products
4. We will send Proforma Invoice or sales confirmation
5. You prepay by T/T or L/C or Western Union through bank
6. We will starting to produce after we get your kind payment
7. Packing
8. Shipping the goods to your(our)forwarder
9. Sending all doc for your custom clearance
10. Time to reorder
Our Advantage:
1. We have more than ten years of sales experience in excavator sealing systems, seal kits, hydraulic pump parts and engine parts in the international and domestic markets.
2. We provide Kobelco, Hitachi, C.A.T, Komatsu, Hyundai, Daewoo and Doosan complete sets for booms, arm, buckets, swing motors, travel motors, main pumps, center joints, crawler adjustment cylinders and gear pumps seals and seal kits.
3. Our Factory have advanced technology and 100% testing before delivery.
4. Quick delivery and competitive price.
5. The larger quantity you order, the better price we can supply.
6. We have a professional team to offer professional service for you.
7. We can offer New and Used, OEM, Good quality, Aftermarket parts to you.
8. All parts can check with part number, all parts can order by part number.
9. Safe packing to protect the goods, such as wooden box, Iron sheet.
Product Show:
